Description
Features
- Built-in temperature and humidity sensor
- Built-in proximity sensor, when the panel detects human body, the LCD screen backlight and button lights can be lit.
- Adjustable LCD backlight brightness
- Different pages for air conditioning, floor heating and ventilation system, and each can be used to control 1 channel device.
- Icons and text support laser labelling
- Enables controls and settings: Page switching, Air conditioner on / off, Air conditioner mode setting, Air conditioner temperature setting, Air conditioner fan speed setting, Static display of ambient temperature & humidity, Floor heating on / off, Floor heating temperature and mode setting, Ventilation on/off, Ventilation fan speed setting, Ventilation mode setting, Backlight brightness setting
- Supports upgrade online
- Supports easy programming
Parameters
- Basic Parameters
- Working voltage: 12~30V DC
- Working current: 30mA/24V DC
- Communication :HDL Buspro
- Cable diameter of Buspro terminal: 0.6-0.8mm
- External Environment
- Working temperature: -5℃~45℃
- Working relative humidity: ≤90%
- Storage temperature: -20℃~60℃
- Storage relative humidity: ≤93%
- Specifications
- Dimensions: 86×86×11(mm)
- Net weight :76g
- Housing material: Glass, PC
- Protection rating (Compliant with EN 60529) :IP20
