Description
Features
- 48-channel, up to 48 separate areas
- 0-99 scenes, running time up to 60 minutes for each, can be set for each area
- Up to 99 sequences supported, 4 running modes (backward, forward & backward, random) available for each sequence
- DMX512 (1990 version)
- Low threshold, high threshold, maximum threshold available for each channel for different devices
- Gateway between HDL Buspro and Ethernet
Parameters
- Basic Parameters
- Working voltage 12~30V DC
- Working current 40mA/24V DC
- Communication HDL Buspro
- RJ45 connection RJ45-TCP/IP network interface
- External Environment
- Working temperature -5℃~45℃
- Working relative humidity ≤90%
- Storage temperature -20℃~60℃
- Storage relative humidity ≤93%
- Specifications
- Dimensions 72mm×90mm×64mm
- Net weight 142g
- Housing material Nylon, PC
- Installation 35mm DIN rail installation
- Protection rating (Compliant with EN 60529) IP20
