Description
Features
- Up to 4 separate areas; max 12 scenes for each area
- Up to 6 sequences and each sequence has 12 steps
- 4 dimming curves with 512 dimming accuracy
- Low, high, max threshold for each channel
- Bypass button for manual control available for each channel
- Selected scene or scene before power off can be activated automatically when the device restarts
- Short circuit and over heat protection
- Up to 3A of each channel, 8A fuse of each channel for protection (aR type)
- Supports HDL Buspro online upgrade
Parameters
- Basic Parameters
- Working voltage ：15~30V DC
- Working current ：28mA/24V DC
- Input voltage ：AC100-240V (50/60Hz)
- Output channel ：4CH/3A
- Maximum total output current ：10A
- Fuse ：8A aR type
- Dimming mode ：TRIAC, minimum load 40W
- Dimming curves ：Linear, 1.5 exponent, 2.0 exponent, 3.0 exponent
- External Environment
- Working temperature ：-5℃~45℃
- Working relative humidity ：≤90%
- Storage temperature ：-20℃~60℃
- Storage relative humidity ：≤93%
- Specifications
- Dimensions ：144mm×90mm×64mm
- Net weight ：715g
- Housing material ：Nylon, PC
- Installation ：35mm DIN rail installation
- Protection rating (Compliant with EN 60529) ：IP20
