Description
Features
- 10 Bit dimming accuracy.
- 6-channel dimming outputs.
- LED indicator status.
- Scene controller.
- Maximum 6 separate areas, each area has 99 scenes and the maximum running time is 60 minutes.
- Up to 99 sequences, each sequence has 99 steps and the time interval is 60 minutes for each step, each sequence has 4 running modes of ”forward”, “backward”, “forward and backward” and “random”.
- Low, high, max threshold for each channel.
- Each channel has emergency bypass button and debugging bypass button
- Each scene, area, sequence, channel should mark up.
- ＊Each channel has current load testing.
- ＊Each channel has MCB status testing.
- ＊MCB switch trip warning.
- ＊Bad lights warning.
- Communication: HDL Buspro
- Provides 400mA current(24V DC) for HDL Buspro.
- Fire protection switch.
- Short circuit and overload protection, earth protection.
- Remote programming and management.
- Device can be restored to previous scene or specified scene, sequence.
Parameters
- Electrical Parameters:
- Input Voltage 220±10%V AC
- Frequency 50Hz±2%
- Power consumption with load Less than 10W
- Output channel 6 channels
- Out current in each channel Max. 12A
- Total current in channel Less than 60A
- Connection Three phase and five wires
- Environment Conditions:
- Working temperature -5℃~45℃
- Working relative humidity < 90%
- Storage temperature -20℃~+60℃
- Storage relative humidity < 93%
- Approved:
- CE
- RoHS
- Product Information:
- Dimensions 470×290×162(mm)
- Net weight 15kg
- Housing material Flame-retardant nylon
- Installation Wall mount
- Protection rating IP20
