Description
Features
- With 2CH 10A relay switch control channel(s)
- With 4 dry contact switch signal input channels, 4 LED switch signal output channels
- With programming button and programming indicator, short press the programming button to control all relay channels on/off
Parameters
- Basic Parameters
- Working voltage ：15~28V DC
- Working current： 65mA/24V DC
- Relay channel ：2CH, 10A/CH (AC100-240V, 50/60Hz)
- Dry contact：4CH dry contact input
- LED：4CH LED output, 12mA/CH
- Communication：HDL Buspro
- Cable diameter of Buspro terminal：0.6-0.8mm
- External Environment
- Working temperature ：-5℃~45℃
- Working relative humidity ：≤90%
- Storage temperature ：-20℃~60℃
- Storage relative humidity ：≤93%
- Specifications
- Dimensions：46.8mm×46.8mm×23.5mm
- Net weight：46g
- Housing material：Flame retardant PC
- Installation：Wall box
- Protection rating (Compliant with EN 60529) ：IP20
