Description
Features
-
Optional backlight RGB colors
-
Door bell for visitors
-
Display requirement of cleaning room
-
1-99 targets can be controlled when user touch the door bell.
-
1-49 targets can be controlled when user swipe the card.
-
The touch sensitivity can be adjusted.
-
Supports upgrade from HDL Buspro
Parameters
- Basic Parameters
- Working voltage 12~30V DC
- Working current 45mA/24V DC
- Supported card type MIFARE ONE S50 13.56MHz
- Communication HDL Buspro
- External Environment
- Working temperature -5℃~45℃
- Working relative humidity ≤90%
- Storage temperature -20℃~60℃
- Storage relative humidity ≤93%
- Specifications
- Dimensions 86×86×10.5 (mm)
- Net weight 119g
- Housing material Glass
- Installation Wall box
- Protection rating (Compliant with EN 60529) IP20
